dji avata goggles DJI Avata 360 Motion Fly More Combo (Goggles N3)

AIRCRAFT

• Takeoff Weight: Approx. 455 g
• Dimensions: 246×199×55.5 mm (L×W×H)
• Max Ascent Speed:

  • 2 m/s (Cine mode)
  • 6 m/s (Normal mode)
  • 10 m/s (Sport mode)
• Max Descent Speed:

  • 1.5 m/s (Cine mode)
  • 6 m/s (Normal mode)
  • 10 m/s (Sport mode)
• Max Horizontal Speed:

  • 6 m/s (Cine mode)
  • 16 m/s (Normal mode)
  • 18 m/s (Sport mode)
• Max Takeoff Altitude: 4500 m
• Max Flight Time: Approx. 23 mins
• Max Hovering Time: Approx. 22 mins
• Max Flight Distance: 13.5 km
• Max Wind Speed Resistance: 10.7 m/s (Level 5)
• Operating Temperature: -10° to 40° C (14° to 104° F)
• Global Navigation Satellite System: GPS + Galileo + BeiDou
• Internal Storage: 42 GB
• Class: C1 (EU)

CAMERA

• Image Sensor: Two 1/1.1-Inch Square CMOS Sensors
• Effective Pixels per Sensor: 64MP
• Lens:

  • FOV: 200°

  • Format Equivalent: 7.8 mm

  • Focal Length: 2.5 mm

  • Aperture: f/1.9

  • Focus mode: FF

  • Focus: 1.5 m to ∞
• Max Image Size: 360° Photo: 15520×7760
• Photo Format: JPEG/DNG (RAW)
• Video Resolution:

  • 360° Mode:

    • 8K (2:1): 7680×3840@60/50/48/30/25/24fps

    • 6K (2:1): 6000×3000@60/50/48/30/25/24fps
  • Single Lens Mode:

    • 4K (4:3)*: 3840×2880@60/50/48/30/25/24fps

    • 4K (16:9): 3840×2160@60/50/48/30/25/24fps

    • 2.7K (4:3)*: 2688×2016@120/100/60/50/48/30/25/24fps

    • 2.7K (16:9): 2688×1512@120/100/60/50/48/30/25/24fps

    • * Only supported when using DJI Goggles 3/N3 paired with DJI RC Motion 3 or DJI FPV Remote Controller 3.
• Video Format: OSV/MP4 (H.265)
• Max Video Bitrate: 180 Mbps
• Color Mode: Normal, D-Log M
• EIS

  • Single Lens Mode:

    • With RC 2/RC-N2/RC-N3: Supports only RockSteady 3.0

    • With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3: Supports a switch between RockSteady 3.0 and HorizonBalancing
• Camera FOV

  • Single Lens Mode:

    • With RC 2/RC-N2/RC-N3: Natural Wide

    • With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3: Standard (Dewarp)/Wide/Natural Wide
• Supported File System: exFAT

GIMBAL

• Stabilization: Single-Axis Mechanical Gimbal (tilt), 360° Virtual Gimbal
• Mechanical Range: Tilt: -95° to 173°
• Controllable Range

  • Single-Axis Mechanical Gimbal:

    • Tilt (With RC 2/RC-N2/RC-N3): -30° to 60°

    • Tilt (With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3): -60° to 60°
  • 360° Virtual Gimbal:

    • Tilt: -180° to 180°

    • Roll: -180° to 180°
• Max Control Speed: 100°/s
• Angular Vibration Range: Single-Axis Mechanical Gimbal: ±0.01°

VIDEO TRANSMISSION

• Video Transmission System: O4+
• Live View Quality:
  • Single Lens Mode: 1080p@100*/60/50/48/30/25/24fps

  • 360° Mode: 1080p@60/50/48/30/25/24fps

    • * In Single Lens Mode, 1080p/100fps is supported only when the aircraft is used with Goggles 3/N3 and RC Motion 3.
• Operating Frequency:

  • 2.400-2.4835 GHz

  • 5.170-5.250 GHz*

  • 5.725-5.850 GHz

  • * 5.170-5.250 GHz can be used only in countries and regions where permitted by local laws and regulations.
• Transmitter Power (EIRP):
  • 2.400-2.4835 GHz:

    • < 33 dBm (FCC)

    • < 20 dBm (CE/SRRC/MIC)
  • 5.170-5.250 GHz:

    • < 23 dBm (CE)
  • 5.725-5.850 GHz:

    • < 33 dBm (FCC)

    • < 30 dBm (SRRC)

    • < 14 dBm (CE)
• Communication Bandwidth: Max 40 MHz
• Max Transmission Distance (unobstructed, free of interference):

  • FCC: 20 km

  • CE: 10 km

  • SRRC: 10 km

  • MIC: 10 km
• Max Transmission Distance (unobstructed, with interference):

  • Strong Interference: Urban landscape, approx. 1.5-4 km

  • Medium Interference: Suburban landscape, approx. 4-10 km

  • Low Interference: Suburb/seaside, approx. 10-20 km
• Max Transmission Distance (obstructed, with interference):

  • Low Interference and Obstructed by Buildings: Approx. 0-0.7 km

  • Low Interference and Obstructed by Trees: Approx. 0.7-4.5 km
• Max Video Bitrate: 60 Mbps
• Max Download Speed:

  • O4+: 10 MB/s

  • Wi-Fi 6: 100 MB/s*

  • * Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, and when internal storage or a high-speed microSD card is used. Download speeds may vary depending on the actual conditions.
• Antennas: 4 antennas, 2T4R

INTELLIGENT FLIGHT BATTERY

• Capacity:≥ 2700 mAh
• Weight: Approx. 149 g
• Nominal Voltage: 14.32 V
• Max Charging Voltage: 17.2 V
• Battery Type: Li-ion
• Energy: ≥ 38.67 Wh
• Discharge Rate: 7C (typical)
• Charging Temperature: 5° to 40° C (41° to 104° F)
• Charging Time:

  • With Charging Hub (100W max charging power):

    • One Battery, From 0% to 100%: Approx. 47 min

    • One Battery, From 10% to 90%: Approx. 31 min

    • Three Batteries, From 0% to 100%: Approx. 100 min

    • Three Batteries, From 10% to 90%: Approx. 70 min
  • Directly Charging the Drone (65W max charging power):

  • One Battery, From 0% to 100%: Approx. 73 min

  • One Battery, From 10% to 90%: Approx. 51 min
• Recommended Charger: Supports DJI 65W Portable Charger and DJI 100W USB-C Power Adapter

BATTERY CHARGING HUB

• Input: 5-20 V, max 5 A
• Output (power accumulation): Max 60 W
• Output (charging): Max 17.2 V
• Compatibility: DJI Avata 360 Intelligent Flight Battery

WI-FI

• Protocol: 802.11 a/b/g/n/ac/ax
• Operating Frequency: 2.400-2.4835 GHz, 5.725-5.850 GHz
• Transmitter Power (EIRP):

  • 2.400-2.4835 GHz:

    • < 20 dBm (FCC/CE/SRRC/MIC)
  • 5.725-5.850 GHz:

    • < 26 dBm (FCC/SRRC)

    • < 14 dBm (CE)

BLUETOOTH

• Protocol: Bluetooth 5.4
• Operating Frequency: 2.400-2.4835 GHz
• Transmitter Power (EIRP): < 10 dBm
